Verisurf Alignment Report

Part Name:

042007 VVSA1 VOLTAGE (SADDLE) LOOPS-AA

Alignment Name:

Auto Align

Coord System:

WORLD

Date:

04/20/07

Fit Results

Name DX DY DZ 3D

3D Point 1 -0.0109 -0.0003 -0.0012 0.0110

3D Point 2 0.0120 0.0053 0.0062 0.0145

3D Point 3 -0.0129 0.0000 -0.0149 0.0198

3D Point 4 0.0119 -0.0049 0.0099 0.0162

Fit Summary

Total Points: 4 DX DY DZ 3D

Maximum Deviation: 0.0120 0.0053 0.0099 0.0198

Minimum Deviation: -0.0129 -0.0049 -0.0149 0.0110

Deviation Range: 0.0249 0.0102 0.0248 0.0088

Average Deviation: 0.0000 0.0000 0.0000 0.0153

RMS Deviation: 0.0119 0.0036 0.0095 0.0157

Standard Deviation: 0.0138 0.0042 0.0110 0.0037

Transformation

X Y Z

Translation: -73.1669 23.2725 -2.3089

Matrix I: 0.5902 -0.1287 -0.7969

Matrix J: -0.7737 0.1912 -0.6040

Matrix K: 0.2301 0.9731 0.0132

3D Point 1	-0.0109	-0.0003	-0.0012	0.0110
3D Point 2	0.0120	0.0053	0.0062	0.0145
3D Point 3	-0.0129	0.0000	-0.0149	0.0198
3D Point 4	0.0119	-0.0049	0.0099	0.0162

Total Points: 4	DX	DY	DZ	3D
Maximum Deviation:	0.0120	0.0053	0.0099	0.0198
Minimum Deviation:	-0.0129	-0.0049	-0.0149	0.0110
Deviation Range:	0.0249	0.0102	0.0248	0.0088
Average Deviation:	0.0000	0.0000	0.0000	0.0153
RMS Deviation:	0.0119	0.0036	0.0095	0.0157
Standard Deviation:	0.0138	0.0042	0.0110	0.0037

	X	Y	Z
Translation:	-73.1669	23.2725	-2.3089
Matrix I:	0.5902	-0.1287	-0.7969
Matrix J:	-0.7737	0.1912	-0.6040
Matrix K:	0.2301	0.9731	0.0132
